Overview

The antenna mainly receives GPS L1/L5 and BDS B1/B2A dual-band signals, and is compatible with signals from other frequency bands of GPS, BDS and GLONASS, which is suitable for multi-system and high-precision measurements.

Key Features

Easy to Install

Standard SMA connectors for power feeding and signal transmission allow the antenna connector to be connected to the signal connector of the end device to secure the antenna without the need for additional mounting holes.

Light to Equip

With a weight of less than 20g, it is especially suitable for drones, handsets, wearable devices and other devices with strict requirements for mass and volume, which can greatly reduce the load burden.

Omnidirectional Radiation

The four-arm spiral structure has better low-elevation gain, wide-angle circular polarization characteristics, and can receive more low-elevation signal.

Waterproof and Dustproof

The antenna is hermetically sealed and IP67 compliant.

Specification Excerpts

Performances

GPS	L1, L2, L5
GLONASS	G1, G2
BDS	B1, B2
Polarization	RHCP
Horizontal plane coverage angle	360°
Axial ratio	≤ 3dB
Impedance	≤ 50Ω

Physicals

Size	Ф23mm×56mm
Weight	≤ 20g
Connection port	SMA-J
Working temperature	-45℃ to +70℃ (-49℉ to +158℉)
Storage temperature	-55℃ to +85℃ (-67℉ to +185℉)
Waterproof level	IP67

Electricals

Supply voltage	3.0V - 5.5V
Current consumption	≤ 25mA
