Satellite CommunicationsKV6
A 65cm Ku-Band Maritime VSAT Antenna System Which is Ideal for Smaller Vessels With Space Constraints
Inquiry
Overview
Key Features
Parameters
Applications
Download
Related Products
Overview
Featuring a compact size and lightweight design, KV6 is a 65cm Ku-Band maritime VSAT antenna system which is ideal for smaller vessels with space constraints. With its 3-axis stabilized platform and 5 patent technologies, KV6 offers superior tracking performance video monitoring, broadband, video conference, VolP and other network applications.
Key Features
High Tracking Accuracy
Adopting an upper inertial navigation scheme, an accurate error model, and efficient compensation and correction of errors, resulting in hightracking accuracy.
Stable and Reliable Tracking
Adoption of reflector surface tracking algorithm, based on three-dimensional relationships of signal level, azimuth angle, and elevation angle, ensuring stable and reliable tracking.
Modem Compatability
Compatible with a variety of modems, iDirect, UHP, Newtec, Gilat, Comtech, Hughes, Anovo, Spacebridge and many more.
Advanced System Control
The ACU has built-in Wi Fi, allowing wireless device users to directly connect. Advanced system control and antenna status monitoring can be achieved using an ACU web interface.
Specification Excerpts
Performances
Stabilization forms

3-axis stabilized:Azimuth,Elevation,Roll

Tracking forms4-axis stabilized:Azimuth, Elevation, Roll, Skew
Tracking &location modeBuilt-in inertial guidance & BDS/GPS
Azimuth range/tracking rateUnlimited/±90°@36S
Elevation range/tracking rate-20°~120°/±20°@3S
Roll range/tracking rate±38°/±25°@4S
Skew range±167.5°
Initial lock≤60S
Re-lock after break lock timeBreak lock<30S; Re-lock<3S
Tracking braking systemAzimuth, Elevation, Roll, Skew



Physicals
Radome height93.6cm (36.85 inch)
Radome diameter81.85cm (32.22 inch)
Reflector diameter65cm (25.59 inch)
Antenna weight43.9kg/96.78lbs
Working temperature-25℃ to +70℃ (-13℉ to +158℉)

Waterproofing grade

IP56
Satellite bandKU-Band

ACU size

350*230*50.98mm (Without bracket)

ACU weight

2.9kg



Electricals


Power input

AC: 100V~240V/50Hz

DC: 15-36V

Power outputDC: 24V
Static power (Without BUC) Average: ≤15W; Peak value: ≤40W
Dynamic power (Without BUC) Average: ≤25W; Peak value: ≤50W
BUC power4W / 6W / 8W / 16W (Optional)



Applications
Merchant Marine Communications Freighter Communications Fishing Vessel Communications Official Ship Cmmunications Emergency Communications
